An organic film that is coated thinly and positioned between the anode and cathode is what makes an OLED (Organic Light-Emitting Diode) a self-lighting device. OLED technology does not require a backlight, in contrast to LCD technology. OLED is thought to be the best technology for the upcoming generation of flat-panel displays since it has a wide range of applications for almost all display kinds.
Using SPI/IIC/I2C protocols, any microcontroller can be interfaced with this 0.96-inch I2C/IIC 4-pin OLED Display Module BLUE. It has a 128 x 64 resolution. The kit contains a display board, a display, and a pre-soldered 4-pin male header to the board.
OLED 128×64 dot matrix display module in monochrome. This display module’s features include low power consumption, broad viewing angle, wide temperature range, high contrast ratio, slim/thin outline, and high brightness.
Interface pin for 4 PIN 128×64 OLED
- VCC: 3.3 volts – 5 Volts
- GND: Ground
- SCL: Serial Clock
- SDA: Serial Data
Features of 4 pin 128 x 64 OLED Display
- Super High Brightness (Adjustable)
- Super High Contrast (Adjustable)
- Embedded Driver/Controller
- Display size: 0.96″
- Resolution radio:128 x 64
- Interface modes: I2C/IIC
- working voltage: 3.3V
- Control Chip: SSD1306
